MONITOR
A47
The Monitor function displays each channel and shows
the movement of channels when sticks, levers and
switches are moved. It renames channels according
to special assignments to assist in identifying what is
moving. For instance, when Flaperon is the wing type, the
Monitor will display RAIL for right Aileron and LAIL for
left Aileron instead of displaying channel 2 and channel
6. It is a handy way to determine what channels are mixed
with other channels and to verify programming when the
aircraft is not at hand. The Monitor function also displays
the current value of all digital trims
1. To access the Monitor function, highlight and
select MONITOR in the FUNC.LIST to obtain
the Monitor display.
2. The default display shows the settings of all digital
trims. To view the Monitor display of all channels,
highlight and select TRIM. View the display while
moving sticks, switches and levers to see the
movements of various channels.
