2.Installation of Scanner Unit > 2.1 Equipment Cable
2-4
Wiring to the Display Unit is shown below. Please refer to the Chapter 3 Installation of Display Unit for
more information.
CQD-2273 Radar Interface Circuit
VD+1.
VD-2.
TRG+3.
TRG-4.
BP+5.
BP-6.
BZ+
7.
BZ-8.
MTR+9.
MTR-10.
MTRG
11.
N.C.
12.
DC+
13.
DC-
14.
V2.
U1. Yellow
Green
Black 1
(Coaxial)
Black 2
(Coaxial)
Black 3
(Coaxial)
Black 4
(Coaxial)
Yellow
White
Braid
White
N.C.
Twisted Pair
Red
Blue
TB838
J832
+ -
