PartsList
NAME TYPE CODE
200K TX/RX UNIT CML-596-2 CML-596-2
(JFE-582) 200kHz
50K TX/RX UNIT CML-596-5 CML-596-5
(JFE-585) 50kHz
I/O UNIT CQD-1705 CQD-1705
JFE-582 POWER UNIT CBD-1488 CBD-1488
(JFE-585) PANEL UNIT CCK-831 CCK-831
RECORDER TRIGGER UNIT CPA-132B CPA-132B
PEN BELT MOTOR H-7DBS7001 7DBS7001
RECORDING BELT MPGK01821 MPGK01821
RECORDING PEN MPXP00791A MPXP00791A
PAPER FEED MOTOR P43AG2130-500(12)6NM 5BPAE00005
RECORDING PAPER J8 6ZPBS00006
MATCHING BOX AW-154F AW-154F
(JFE-582) 200kHz
MATCHING TRANS. TD-LD169-42 6LHBS00120
JUNCTION BOX AW-154F-50 AW-154F-50
(JFE-585) 50kHz
*ONLY JUNCTION BOX
TRANSDUCER 200kHz UT-200ND20 5UNAB00015
TRANSDUCER (JFE-582) 200kHz
TRANSDUCER 50kHz UT-50MD20 5UNAB00134
(JFE-585) 50kHz
JFE-585 50kHz
53
