2-5
2.2 INSTALLATION PROCEDURE
1) Precautions for transporting and storing the antenna
x An antenna is a heavy load. Be very careful about handling it.
x Do not allow the antenna fall on its side while it is stored or being installed.
x Do not apply rope to the antenna in the way that squeezes or deforms the radiating section.
x When hoisting the antenna by a crane, do not hoist it by attaching a belt or a rope only to
the antenna's radiating section as shown in Fig. 6.
x For the X-band, wrap a cloth around the antenna's support section located at the bottom of
the radiating section, and then attach a belt or rope to it to hoist the antenna
(Fig. 8).
Fig. 6 Improper way to hoist
Fig. 8 X-band
