3-1
The display unit consists of:
Radar process unit: NDC-1460
Operation unit: NCE-7699A
LCD monitor NWZ-164
3.1 SELECTING THE INSTALLATION
POSITION
Select a display unit installation position by taking into consideration the following:
1) Install the display unit so that the user can easily conduct observations.
2) To reduce effect on the magnetic compass, install the display unit more than one meter away from the
compass.
3) Take precautions to prevent water from splashing through the window or door of the bridge onto the
display unit.
4) Install the display unit by considering convenience of maintenance.
If the display unit is adjacent to machinery or walls on the right, left, above or behind, allow enough slack
in the installation cable so that the display unit can be pulled forward for maintenance and inspection.
5) Install the LCD monitor so that when the user is looking ahead, the lookout view is not obscured.
6) Install the unit away from direct sunlight and heat source.
