3-55
(4) Connect key-board cable to the circular connector of CFQ-5351 attached on the cabinet.
Note To turn off the system, turn off the power on both of the two key-boards,
main key-board and sub key-board.
Especially the power switch on the multi-function key-board is mechanical switch.
If it is not switched off, the system is powered on by the breaker.
2) Setting
No special setting is required for using the sub key-board.
After the power is turned on, the sub key-board can be used.
Note As the main key-board and the main key-board can be used concurrently, the radar
utilization status may have been changed through the operation of the other key-board.
When using two key-boards by connecting a sub key-board, keep in mind that the operation
status may be changed without notice through the operation on the other key board.
To Next Page
