3-38
3
3.5 Use Own Ship's Track Data
y
y y
If the own ship track display (DISP Own Track) is turned off when own ship track
data is in storage, own ship's tracks are not shown on the radar display, but own
ship's track data is still saved.
3.5
USE OWN SHIP’S TRACK DATA
The own ship's track function saves and displays own ship's track.
If navigation equipment is connected, this radar system records latitude/longitude data sent from the
navigation equipment and displays own ship's track.
3.5.1 Set Display Color of Own Ship’s Track
(DISP Own Track Color)
Own ship's track data can be saved in seven different colors.
Own ship's track data can be displayed or not displayed individually by color.
Procedures 1 Open the Display Own Track Setting menu by performing the menu
operation.
Main
→ Own Ship Setting
→ Own Track Setting
→ DISP Own Track Color
The Display Own Track Setting menu will open.
Operations differ according to the following set modes.
When 1.All is set to On All of own ship's tracks are displayed.
When 1.All is set to Off All of own ship's tracks are not
displayed.
When 1.All is set to Individual Settings are made by color by
performing the operation below.
2 Left-click the color button for the desired display setting which is to be
changed.
Display of each item is switched between On and Off .
On : Own ship's track plotted by the color is displayed.
Off : Own ship's track plotted by the color is not displayed.
Note:
If the own ship track display is turned off when own ship track data is in storage, own ship's
tracks are not shown on the radar display, but own ship's track data is still saved.
