3-18
3
3.3 Operation Procedures
y
y y
3.3.6 Operation on Numeric Value, Latitude / Longitude and
Character Input menu
When a numeric value must be entered while operating this radar system, the numeric value input screen
will appear. In that case, enter a numeric value according to the following operation method.
Numeric value input screen
Directly entering a numeric value
Procedures 1 On the numeric value input screen, sequentially left-click the software
number keys located on the radar screen, and enter a desired numeric
value.
For example, when entering 123.4 for a numeric value, sequentially left-click the software
number keys as shown below.
1 → 2 → 3 → 4
※ A numeric input outside the input range is not accepted.
When left-clicking CLR button, the value is canceled.
2 When plus and minus of the input value is changed, set the value
with - or + button.
3 Make sure that the entered value is correct, and left-click the ENT
button.
The set value is reflected to the operating state.
Numeric button
Clear button
Close button
Enter button
+ button
- button
Input range
