7.2 Settings
yyy
yyyy
7
[II] Sector Blank Area Creation (Make Sectors 1, 2, and 3)
Procedures 1. Open the Serviceman Menu.
2. Perform the following menu open procedure to open the Sector Blank
setting menu.
Installation Menu
→ Sector Blank
3. Select the sector blank number for sector creation, and click the
Make Sector 1 --- M ake Sector 3 button in the menu.
The selected sector blank will be made.
4. Set the starting azimuth of the sector blank by operating the [EBL] dial,
and press the [EBL] dial.
The start angle of the sector blank will be set.
5. Set the ending azimuth of the sector blank by operating the [EBL] dial,
and press the [EBL] dial.
The end angle of the sector blank will be set.
