5-46
5.5 Alarm Display
yy
yyy
5
CAUTION
In setting an automatic acquisition zone, it is
necessary to adjust the gain, sea clutter
suppression and rain / snow clutter suppression
to ensure that target echoes are displayed in the
optimum conditions. No automatic acquisition
zone alarms will be issued for targets undetected
by the radar, and this may cause accidents such
as collisions.
Alarm for New Target Acquired in Automatic Acquisition Zone (New Target)
The automatic acquisition function sets a zone in a range and issues an alarm when a new target (which is not
yet acquired) goes into this zone.
For the setting of an automatic acquisition zone, refer to " Acquiring Target " in Section 5.2.1.
Alarm for New Target Acquired in Automatic Acquisition Zone
Status Symbol on display Alarm characters Alarm sound Conditions
New target in
automatic
acquisition zone
Red Blinking
New Target
Beep sound (pipi-pipi)
Alarm
acknowledgeable
The alarm is issued when a
new target is acquired in the
automatic acquisition zone.
Note:
When an already acquired target goes into automatic acquisition zone, the alarm message is not
displayed and the buzzer does not sound either.
12
