3.7 INITIAL OPERATION AND CHECK OUT
3.7.1 INSPECTION AFTER THE INSTALLATION
After completing the installation and prior to energizing the equipment, it is
necessary to assure that all the steps of the installation were accomplished in
accordance with the instructions.
(1) The cables are not crimped or damaged.
(2) The input voltage connected accurately.
(3) The securing bolts of all equipment is tightened.
(4) The connection of the power cable shield is made properly to RF
ground.
3.7.2 OPERATING INITIAL SETTING MENU
Press the JOYSTICK, and the initial setting menu will be appear on the screen.
The JOYSTICK is used to select a particular menu. The particular menu will be
highlighted character, then press the JOYSTICK.
3.7.3 RELATIVE BEARING ALIGNMENT
This alignment should be made when the radar unit is installed. Failure to per-
form this procedure can result in incorrect target bearing readings.
Proceed as follows:
Identify a suitable targets (e.g. buoy, etc.) preferably between 0.5 and 1 NM
in range on the screen.
Visually locate the target and line the bow of the vessel up with the target.
Put the EBL marker on the target.
Press and hold the JOYSTICK for the initial setting menu.
Select BEARING by using the JOYSTICK, press the JOYSTICK for the
bearing adjustment mode.
INSTALLATION
