JRC Radar 3000 - Appendix; Radar 3000 Scanner Unit (Nke-1046) Radome Template

forwordaft
BREATHING
TUBE
φ 0.591" ( φ 15mm)
φ 1.14" ( φ 29mm)
4-
φ 0.47" ( φ 12mm)
5 9/16" (141.7mm)
3.149"
(80mm)
CABLE
ACCESS
4.330"
(110mm)
5 9/16"
(141.7mm)
Fig.1 RADAR 3000 SCANNER UNIT (NKE-1046)
RADOME TEMPLATE
