1. INSTALLATION
1) Carry the sewing machine with two persons as
shown in the gure above.
(Caution) Do not hold the handwheel.
23.5 mm
19.5 mm
1
2
4
3
A
B
1
1
3
3
8
2) Do not put protruding articles such as the screw-
driver and the like at the location where the sew-
ing machine is placed.
3) The under cover should rest on the four cor-
4) Fix two rubber seats
1
on side
A
(operator’s
ners of the machine table groove. Mount rubber
side) using nails
2
as illustrated above. Fix two
hinge seat
8
on the table and x it on the table
cushion seats
3
on side
B
(hinged side) using a
with a nail.
rubber-based adhesive. Then place under cover
4
on the xed seats.
5
C
5) Remove air vent cap
5
attached to the machine
bed.
(Caution)
1. If the sewing machine is operated without re-
moving air vent cap
5
, oil leakage from gear
box portion C may occur.
2. Be sure to attach cap
5
when transport-
ing the machine head in the state that the
machine head is removed from the machine
table.
