– 1 –
I. SPECIFICATIONS
S : Light- to Medium-weight materials
DDL-900A-
DDL-900A-S
Application
Light- to Medium-weight materials
Max. sewing speed 5,000 sti/min
Thread trimming speed 300 sti/min
Stitch length 4 mm
Presser foot lift (by knee lifter) 13 mm
Needle
*1
DB × 1 (#14) #9 to 18, 134 (Nm 90) Nm 65 to 110 (for CE)
Lubricating oil NEW DEFRIX OIL No.1 or JUKI CORPORATION GENUINE OIL 7
Noise
- Equivalent continuous emission sound pressure level (L
pA
) at the workstation :
A-weighted value of 81.0 dB; (Includes K
pA
= 2.5 dB); according to ISO 10821-
C.6.2 -ISO 11204 GR2 at 4,000 sti/min.
A-weighted value of 80.0 dB; (Includes K
pA
= 2.5 dB); according to ISO 10821-
C.6.2 -ISO 11204 GR2 at 3,500 sti/min.
• The sewing speed preset at the time of shipping : 4,000 sti/min
*
1
: Needle used depends on the destination.
Supply voltage Single phase 220 to 240V
Frequency 50Hz/60Hz
Operating environment
Temperature : 5 to 35˚C
Humidity 35 - 85 %
Input 210VA
