– 46 –
15. LED hand light
The sewing machine is provided as standard with an
LED light which illuminates the needle entry area.
1) Turn the power ON while pressing switch
to enter the function setting mode.
2) Intensity adjustment and turn-off of the light is
carried out by pressing switch ❶. Every time the
switch is pressed, the light is adjusted in intensity
in ve steps and is turned off in turn.
[Change of intensity]
1
⇒
......
4
⇒
5
⇒
6
Bright
⇒
...... Dim
⇒
Off
⇒
Bright
In this way, every time the switch ❶ is pressed,
the hand lamp status is changed in repetition.
3) Press switch to complete the proce-
dure.
16. Height adjustable one-touch type reverse stitching switch
Height of touch-back switch ❶ is adjustable.
For the process during which touch-back switch ❶
is not used, the material on the sewing machine can
be handled with ease by increasing the height of the
switch.
[How to adjust the height]
The switch height can be adjusted along the bracket
by loosening screw ❷.
WARNING :
In order to protect against personal injury due to unexpected start of the sewing machine, never bring
hands near the needle entry area or place foot on the pedal during the adjustment of intensity of the LED.
❶
❸
To change the settings of wiper ❸ from the factory-adjusted settings at the time of shipment for
the purpose of adjustment, it is necessary to adjust the height of touch-back switch ❶ so that it
does not interfere with wiper ❸.
❷
❶
* This LED is intended to improve operability of the sewing machine and is not intended for
maintenance.
❷
