DLN-6390, DLN-6390-7 (September, 2003) 1/2
● The needle bar stroke is as high as 35mm. This offers increased
penetration of the needle into the material to improve adaptability
to heavy-weight materials.
● The machine demonstrates excellent sewing capabilities, when
sewing heavy-weight denim or multi-layered portions, that free it of
sewing troubles such as stitch gathering, stitch skipping and needle
breakage.
● The machine is able to sew material with a low presser foot
pressure while preventing the material from flapping. As a result,
the material can be sewn free of puckering.
● The top- and bottom-roller style feed mechanism forms seams with
increased consistency to achieve improved hemming quality while
reducing uneven hems.
SPECIFICATIONS
High-speed, Cylinder-bed, 1-needle, Needle-feed Lockstitch Machine
with Large Hook
DLN-6390
DLN-6390-7
(with automatic thread trimmer)
WHEN YOU PLACE ORDERS
DLN-6390-7
Model name DLN-6390 DLN-6390-7
Application Bottom-folding and hemming (lockstitch type)
Max. sewing speed 5,000rpm
Stitch length
Standard gears: 3.2mm (2.8mm) / Supplied gears: 2.3mm, 3.6mm /
Optional gears: 2.1mm, 2.5mm, 4.2mm (utilized by changing pitch conversion gears)
Needle
SCHMETS UY180GVS Nm140
range of use: Nm90 ~ Nm150 (equivalent to #14 ~ #22.5)
Needle bar stroke 35mm
Hook Automatic-lubrication type exclusive full-rotary 1.7-fold hook
Lift of the presser foot Max. 14mm
Feed system Top- and bottom-roller style
Binder open/close type Manual type Driven by air cylinder
Compressed air and
air consumption
― 0.5MPa (0.5kgf/F), 10NR/min
Lubrication JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Cylinder-bed diameter 180mm
Weight of the machine head 34.5kg 36.5kg
● Without automatic thread trimmer ● With automatic thread trimmer
DLN6390S DLN6390S7W0
Application Code
Standard S
Application Code
Standard S
Wiper and automatic reverse feed function
Wiper
Automatic reverse feed
function
Code
Provided Not provided W0
Option Code
Not provided Z
With needle cooler A
