TU-273, TNU-243 (September, 2003) 1/1
TNU-243
SPECIFICATIONS
WHEN YOU PLACE ORDERS
● The machine has a wider free space under the machine arm to
allow the operator to easily place and remove a large sewing
products.
● The machine comes with a large shuttle-hook. This type of
shuttle-hook helps to reduce the frequency of bobbin thread
replacement and is best suited for the sewing of extra heavy
materials sewn with lower-count threads.
● The lifting range of the presser foot is as high as 20mm for
smooth placement/removal of extra heavy materials.
● TU-273
The top-feed amount is adjustable within the range of ±20%
of the bottom-feed amount.
● TNU-243
Thanks to the TNU-243's unison-feed mechanism, the machine's
higher feed efficiency guarantees the output of high-quality
seams free from uneven material feed.
TU-273
(top & bottom-feed)
TNU-243
(unison-feed)
1-needle, Semi-long Flat-bed, Lockstitch Machine
with Large Shuttle-hook for Extra Heavy Materials
Model name
Feed system
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Alternating vertical movement
Thread take-up
Hook
Needle (at the time of delivery)
Thread
Lubrication
Lubricating oil
Bobbin winder
Distance from needle to machine arm
Bed size
Weight of the machine head
800rpm
15mm (normal/reverse feed)
56mm
By hand: 12mm, By pedal: 20mm
4〜8mm
Cam-type
Large shuttle-hook
794 (Nm230) Nm130〜Nm280 or DY×3 #21〜#28
#8〜#0, B92〜B277, Nm=30/3〜8/3
By an oiler
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Built on the machine arm
420mm
656mm×253mm
65kg
Auto-lifter
Not provided
Knee switch type (AK72A)
Pedal switch type (AK72B)
Code
A
B
TU273/ TNU243/
TU-273
Top & bottom-feed
TNU-243
Unison-feed
