LBH-780 Series (September, 2003) 3/3
Set
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
Stitch No.
54
62
66
70
74
79
83
88
93
100
105
110
115
123
130
Small gear
Large gear
Part No.
B2936-761-000
B2938-761-000
B2940-761-000
B2942-761-000
B2944-761-000
B2946-761-000
B2928-761-000
B2948-761-000
B2950-761-000
B2930-761-000
B2952-761-000
B2932-761-000
B2954-761-000
B2934-761-000
B2956-761-000
Stitch No.
345
300
285
268
252
238
225
212
200
190
180
170
160
152
145
Stitch No.
B2937-761-000
B2939-761-000
B2941-761-000
B2943-761-000
B2945-761-000
B2947-761-000
B2929-761-000
B2949-761-000
B2951-761-000
B2931-761-000
B2953-761-000
B2933-761-000
B2955-761-000
B2935-761-000
B2957-761-000
EXCHANGING PARTS
● Table of changing gears
No.
1
2
3
4
5
6
7
8
9
10
11
Size
6.4mm (1/4")
9.5mm (3/8")
12.7mm (1/2")
14.3mm (9/16")
15.9mm (5/8")
19.1mm (3/4")
22.2mm (7/8")
25.4mm (1")
31.8mm (1-1/4")
34.9mm (1-3/8")
38.1mm (1-1/2")
Knife
A
Work clamp check
B
Throat plate
C
Part No.
B2702-047-F00
B2702-047-K00
B2702-047-L00
B2702-047-V00
B2702-047-M00
B2702-047-N00
B2702-047-P00
B2702-047-Q00
B2702-047-S00
B2745-774-00A
B2745-774-00B
Part No.
B1552-781-000-A
B1552-782-000
B1552-783-000
B1552-784-000
Part No.
B2402-771-000
B2402-774-000
● Table showing parts used in connection with knives
Note: Standard model machine is used as the standard for work clamp check and throat plate.
9
