LZ-2280N, 2281N, 2282N, 2282N-7, 2284N, 2284N-7, 2286N, 2288N, 2285N, 2280NU, 2284NU, 2284NU-7 (September, 2003) 5/6
LIST OF THE MAJOR GAUGES
Max. zigzag width/
Max. feed pitch
Throat plate Feed dog Presser foot (with finger guard) Remarks
Max.
feed amount: 2mm
Max.
feed amount: 2mm
Max.
feed amount: 2mm
Max.
feed amount: 2mm
Max.
feed amount: 2mm
Max.
feed amount: 2mm
Max.
feed amount: 1.3mm
Max.
feed amount: 5mm
Max.
feed amount: 2.5mm
Max.
feed amount: 1.6mm
With a recess on the reverse side of
the presser foot
Light-in-weight type
Light-in-weight type
Light-in-weight type
Light-in-weight type
Presser foot with tape guide
Front fulcrum type
Light-in-weight type with the
front fulcrum
Light-in-weight type with the
front fulcrum
• Suited to
sewing tasks
that require
frequent
changes in the
needle throw
position.
• Light -in-weight
presser foot
prevents
jumping at the
time of
high-speed
sewing.
Max. 15.6
Max. 2
100-41010
100-47017
225-80104
225-80500
225-82209
225-82803
225-81508
225-48804
225-40009
225-45107
225-45610
100-41101
225-80005
225-82100
225-82704
225-82407
225-82506
225-45008
225-45511
225-45867
225-45362
MAB-109000B0
225-84965
225-80864
235-03204
235-03154
225-80765
225-80260
225-80369
4
