JUKI DLN-9010 Handbook

MF-7722E10B40/MD10, MF-7723E10B□□/MD10 (September, 2004) 2/2
WHEN YOU PLACE ORDERS
SUBCLASS MACHINE LIST
LIST OF E10 GAUGES AND KNIVES
＊1 Stitch length can be adjusted to 4.4mm at the maximum. ＊2 3mm with top coverstitch, 6mm without top coverstitch.
Seams Model No. Number of
needles
Number of
threads
Needle gauge
(mm)
Stitch
length (mm)
Differential-
feed ratio
Presser lifting
amount (mm)
Max. sewing
speed (rpm)
Device
Subclass machines
MF-7722-E10-B40 2 4 4.0 1.2〜3.6 1:0.7〜1:1 3 (6) 5,500 MD10, TC13
MF-7723-E10-B56 3 5 5.6 1.2〜3.6 1:0.7〜1:1 3 (6) 5,500 MD10, TC13
MF-7723-E10-B64 3 5 6.4 1.2〜3.6 1:0.7〜1:1 3 (6) 5,500 MD10, TC13
E10
For attaching elastic
＊1 ＊2
Stitch type Code
2-needle, top and
bottom coverstitch
22
3-needle, top and
bottom coverstitch
23
Application Code
For attaching
elastic
E10
Tonque shape of
throat plate
Code
B type (standard) B
Needle gauge Code
4.0mm 40
5.6mm 56
6.4mm 64
For model category (23)
(3-needle), needle gauge
category 40 cannot be
selected.
＊1 Specify the MD10 when placing your order.
＊2 The TC13 can be retrofitted to the machine.
Device and attachment Code
Not provided
Mechanical type
metering device
MD10
Electromagnetic type
tape cutter
TC13
MF77 E10B / /
＊1
＊2
Model name MF-7722E10B40 MF-7723E10B56 MF-7723E10B64
Needle gauge 4.0mm 5.6mm 6.4mm
Needle clamp 13350103 13350301 13350400
Throat plate 13356001 13356209 13356308
Presser foot asm. 40018288 40018289
Main feed dog 13354006 13354105
Differential-feed dog 13358106 13358205
Moving knife 40016780
Lower knife 13150701
www.egemakine.com.tr

JUKI DLN-9010 Specifications

General

Motor	Direct-drive servomotor
Max Sewing Speed	5, 000 stitches per minute
Needle Type	DPx5
Lubrication	Automatic
Dimensions	580 x 220 x 370 mm
Weight	38 kg
