JUKI LK-1900BN Series User Manual


5

3-3. Attaching the connecting rod
3-4. Installing the head support rod
󰿿
󱀀
󰿿
󱀀
󱀁
󱀁
󱤨
󱤩
1) Fix connecting rod
󰿿
to installing hole B of pedal
lever
󱀀
with nut
󱀁
.
2) The pedal depressing stroke is decreased by
tting connecting rod
󰿿
in mounting hole A.
Drive head support rod
󰿿
in hole
󱀀
in the machine
table.
