(6) Semi-submerged down table for MFC
2
Table Part No.30148308
5-ø26, 19 deep
78.5123.5
60
80
60
471
214
136
30
185 ±1
143 ±1
20 ±1
258
23
32 ±1
46
R4
116
262 ±1
242 ±1
413 ±1
ø32
15
4-ø10
25
64
143
ø20
143
164 ±1
35
125
80
70 ±1
40
120 ±1
40
R2 (Entire round)
R2 (Entire round)
20
(40)
10
R2
R2
