JUKI MF-7000 Series - Zigzag Stitching Machine; LZ-2290 SS; LZ-2290 SS-7

−67 −
1) Parts used
2) Assembling and adjustment of spreader thread guide
!2
!3
!4
!4
(4) Spreader thread guide
Normally, use the hole on lower side.
Standard Adjustment
To align height
of holes (At the
time of needle
bar upper dead
point)
Use the thread hole located in extreme rear position.
