JUKI MP-200N Series - Feed Dog Height Adjustment; Feed Vertical Movement Adjustment

−5 −
Standard Adjustment
(2) Adjusting the height of the feed dog
Standard Adjustment
(3) Adjusting the vertical movement of the feed
™MP-200NS
0.4 to 0.5 mm
™MP-200NL
0.6 to 0.7 mm
1
2
Conditions : Stitch dial scale : “0”
: Turn handwheel to bring needle
bar to its upper dead point.
1
2
3
