– 29 –
[Two-reverse-step pedal type]
High speed /
Low speed
Stop (neutral) /
Presser foot lifting (AK- □□□
Thread trimming /
（AK- □□□ A）
（2）How to use
1) When the pedal is in the neutral position, press the knee switch (AK-□□□A) or lightly depress the back part
of the pedal (AK- □□□ B), and the presser foot can be raised as long as you keep either of them held
depressed.
2) The presser foot automatically goes up after thread trimming, and the presser foot is lowered by depressing
the front part of the pedal to allow the machine to start sewing.
Presser foot can be lowered by depressing the knee switch once and returning it to the home position
(AK-□□□ A) or depressing the back part of the pedal and returning it to the neutral position (AK- □□□ B).
Knee switch /
