JUKI SC-510 - Block Diagram of Connection of Relay Cord

– 18 –
Relay cord /
Synchronizer installed after set-up for SC-510 /
Sewing machine connector (12P) /
CN33(7P)
CN36(14P)
CN50-1(4P)
CN50-2(4P)
CN50-3(4P)
CN50-4(4P)
CN51-1(4P)
CN51-2(4P)
CN51-3(4P)
CN51-4(4P)
Switch connector (16P)
Solenoid valve connector (10P) /
Extension solenoid valve
connector (14P blue) )
Connector for AE (8P)/
Threadingg switch connector (4P) /
・Connect white line to 4 pin of CN36
and black line to 11 pin of CN36.
SC-510
Unused
Knee switch
Auto-lifter device (AK) /
(2) Block diagram of connection of relay cord
