AK DEVICE (FOR THE SEWING MACHINE PROVIDED WITH AN AK DEVICE)
(1)Installing and connecting the AK device
1) After the sewing machine has been set up, attach solenoid valve installing plate 1, knee switch (asm.) 2 (AK-
□ □A) to the underside of the table with wooden screws 3 supplied with the unit.
6
3
4
1
2
3
DU-141H-7 / DSU / LZH-1290-7
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
