– 22 –
[ PLC-1600-7 series / SC-510, DU-141H-7 / SC-510, DSU series / SC-510, DSC series / SC-510, LZH-1290-7 / SC-510 ]
Synchronizer installed after set-up for SC-510
・Connect white line to 4 pin of
CN36 and black line to 11 pin of
CN36.
SC-510
Knee switch
Auto-lifter device (AK)
CN33(7P)
CN35(14P)
CN50-1(4P)
CN50-2(4P)
CN50-3(4P)
CN50-4(4P)
CN51-1(4P)
CN51-2(4P)
CN51-3(4P)
CN51-4(4P)
