JUKI SC-510 Instruction Manual Supplement

– 38 –
Pin No.
1
2
3
4
CN50-4 connector
?4P for output
Function
＋ 24V
Sewing machine running signal
Vacant
GND
Pin No.
1
2
3
4
CN50-2 connector
?4P for output
Function
＋ 24V
DL（−）
2P（−）
GND
Pin No.
1
2
3
4
CN50-1 connector
?4P for output
Function
＋ 24V
ＦL（−）
ＢＴ（−）
GND
Pin No.
1
2
3
4
CN50-3 connector
?4P for output
Function
＋ 24V
Condensation solenoid valve (–)
Short thread remaining (–)
GND
