Operating controls and functional elements
7.2. F500, F1000
1
Main switch, splash water proofed with integral MCB.
I = On
O = Off
2 Indication elements
2(1)
- LED Temperature display
2(2)
- Control display “Cooling”
2(3)
- Control display „Alarm“
3
Foil key pad, splash water proofed
3(1)
- Modify keys for Setpoint – higher / lower
3(2)
- Enter key for storage of Setpoint / Parameter
4
Level indication
5
Filling hole
6
Hand grip
