6.2. Tubing
Damage caused by leaking bath fluid!
• Employ suitable connecting tubing
• Make sure that the tubing is securely attached.
• Avoid sharp bends in the tubing, and maintain a sufficient
distance from surrounding walls.
• Regularly check the tubing for material defects (e.g. for cracks).
• Preventive maintenance: Replace the tubing from time to time.
• Do not seal the overflow !
•
In case the system to be cooled is located at a higher level than
the recirculating cooler, take note of bath liquid flowing back
when the unit is switched off.
The following questions shall help to recognize possible dangers and to reduce the
risks to a minimum.
• Are all tubes and electrical cables connected and installed?
Note:
sharp edges, hot surfaces in operation, moving machine parts, etc.
• What to do when a dangerous substance was spilled on or in the unit?
Before starting to work, obtain information concerning the substance and determine the
method of decontamination.
The units have the following dimensions to connect the tubing:
F250
F500
F1000
Feed ( )
M10x1 male or barbed
fittings
∅ 8/10 mm inner
diameter.
M16x1 male or barbed
fittings
∅ 8/12 mm inner
diameter.
M16x1 male or barbed
fittings
∅ 8/12 mm inner
diameter.
Return ( )
M10x1 male or barbed
fittings
∅ 8/10 mm inner
diameter.
M16x1 male or barbed
fittings
∅ 8/12 mm inner
diameter.
M16x1 male or barbed
fittings
∅ 8/12 mm inner
diameter.
Further accessories can be found at JULABO-Homepage www.julabo.com.
16 1.951.4806-V2
