Julabo FC600 - Menu Functions; Navigating the Configuration Level

Recirculating coolers
35
10. Menu functions
Set the parameters for the recirculating cooler via the
configuration or calibration level.
10.1. Selecting/exiting the configuration level
+ 1x
+ 1x
Simultaneously press the "MENUE" key (4.2)
and
the edit key " " to select the configuration level
or
the edit key " " to exit the configuration level.
+
Select the menu items of the configuration level one by
one by pressing simultaneously the menu key and one of
the cursors.
10.2. Setting the parameters
+ 1x
ACTUAL
SET
+3x
ACTUAL
SET
Example: Baud rate
c Select the configuration level by pressing the keys
simultaneously.
d Select the menu item by pressing simultaneously the
menu key and one of the cursors.
(example: press the cursor key " " 3 times).
e Set the baud rate (4800 Bauds) with the edit keys (" "
or " ").
f Press the enter key to store the new parameter.
