JUMO 4AP-30 - 3-Wire Circuit

8
4.3.2 3-wire circuit
Common minus lead (ground) for supply voltage and measurement
signal.
(Output e.g. 0 – 10 V; 0 – 20 mA; 1 – 6 V)
Connection with terminal box Connection with plug M12
Connection with connecting cable (Extra code /73)
L1
N
L+
L-
0V / S-
U
B
S+
Power
supply
P
I (U)
+
+
+
-
-
+
-
Output
Evaluation
(recorder)
(indicator)
1
2
3
0V / S-
U +
B
P
I (U)
S+
Shielding
Abschirmung
0V / S-
U +
B
P
I (U)
S+
1
4
2
3
0V / S-
U +
B
P
I (U)
S+
(1)
(yellow) (3)
(2)
(white)
(grey)
(black)
Shielding
