83
7 Modbus address t
ables
7.3.25
Compiled writing frames
Modbus address
Signal designation
Dat
a type
Access
Hex.
Dec.
0x8800
34816
Write Frame 1
Byte[254]
R/O
0x8880
34944
Write Frame 2
Byte[254]
R/O
0x8900
35072
Write Frame 3
Byte[254]
R/O
0x8980
35200
Write Frame 4
Byte[254]
R/O
0x8A00
35328
Write Fr
ame 5
Byte[254]
R/O
0x8A80
35456
Write Fr
ame 6
Byte[254]
R/O
0x8B00
35584
Write Fr
ame 7
Byte[254]
R/O
0x8B80
35712
Write Fr
ame 8
Byte[254]
R/O
82
84
Table of Contents
Default Chapter
3
Table of Contents
3
1 Safety Information
7
Warning Symbols
7
Note Signs
7
2 Modbus Protocol Description
9
Master-Slave Principle
9
Transmission Media for Modbus
10
Structure of a Modbus Telegram
10
Function Codes
11
Reading N Words
12
Writing One Word
13
Writing N Words
14
Data Types
15
Examples of Data Transmission
17
Integer Values
17
Floating-Point Values
18
Character Strings (Texts)
19
Checksum (CRC16)
21
Error Messages
22
Modbus Error Codes
22
Error Messages for Invalid Values
23
Error Codes as Integer Return Values
24
3 Interfaces
29
Location of Interfaces
29
Interfaces
30
USB Device, USB Host, and COM 1 Interfaces as Standard
30
COM 2 Interface Can be Expanded Using Optional Boards
30
Terminating Resistors
31
Configuring Interfaces
32
4 Modbus Via a Serial Interface
37
Modbus Timing for Serial Interface RS422/485
37
Modbus Master Operation
38
Modbus Slave Operation
40
5 Modbus and Other Protocols over Ethernet
41
Modbus/Tcp Protocol
41
Networking with Modbus/Tcp
43
Modbus Master with Modbus/Tcp
43
Modbus Slave with Modbus/Tcp
44
Http
44
Browser Connection and Web Server
45
E-Mail (SMTP and POP3)
46
6 User Frames
49
General Information
49
Structure of the Reading and Writing Processes
49
Compiling Modbus Frames
51
Modbus Frames for Reading
51
Modbus Frames for Writing
54
Examples for the Data Transmission Options with Frames
57
7 Modbus Address Tables
59
Data Types and Access Types
59
Configuration Data and Parameters
60
Device Software Version
60
Device Name
60
Limit Values for Limit Value Monitoring 1 to 16
60
Ramp Slope, Controllers 1, 2
61
Controller 1, Parameter Block 1
61
Controller 1, Parameter Block 2
61
Controller 1, Parameter Block 3
62
Controller 1, Parameter Block 4
63
Controller 2, Parameter Block 1
63
Controller 2, Parameter Block 2
64
Controller 2, Parameter Block 3
65
Controller 2, Parameter Block 4
65
Setpoint Values, Controller 1
66
Setpoint Values, Controller 2
66
Filter Time Constant, Offset
66
Analog and Digital Flags 1 to 8
67
Controller Type, Control Direction
67
Process Values
68
Transmission Times of the Frames
68
Date, Time
68
Measuring Inputs 1 to 4
68
Controller 1
69
Controller 2
69
Setpoint Values, Controller 1
69
Setpoint Values, Controller 2
70
Program Controller
70
Math, Logic
72
Digital Inputs 1 to 7 and Their Alarms
73
Limit Value Monitoring, Actual Values and Alarms
73
Digital Control Signals
74
Timers
75
Analog and Digital Flag
76
Device Operation
76
Outputs
78
External Analog and Digital Signals
78
Modbus Error
80
Data, Controller 1
80
Data, Controller 2
80
Program Editor Memory
81
Program Editor Memory, Section 1, 2 to 50
81
Program Name
82
Compiled Reading Frames
82
Compiled Writing Frames
83
