3 Operation - Configuration - Parameterization
18
3.2.5 Timer (tFCt)
The timer provides an output signal available for the binary functions. This signal can be used,
e.g. to realize a time-limited control or a time-dependent setpoint changeover.
The timer value is not saved during a mains failure. After the mains connection is restored, the
timer remains inactive.
ConF -> tFCt ->
Response at
Out-of-Range /
symmetry of limit
value
ACrA
0 Off / symmetric (only AL is active)
1 On / symmetric (only AL is active)
2 Off / asymmetric (AL and AL2 are active)
3 On / asymmetric (AL and AL2 are active)
Switching state in the event of overrange or underrange ("Out-
of-Range“) / symmetry of alarm functions AF1, AF2
Switch-on
delay
tOn
0 ... 9999 Switch-on delay of the output signal (in seconds)
Actual value
AFPr
2 Signal to be monitored; 2 = actual value
Ö
"Analog selector", page 15
Setpoint value
AFSP
3 Setpoint for limit value monitoring (reference signal for AF1 to
AF6); 3 = current setpoint
"Analog selector", page 15
Parameters Value Description
Function
FnCt
0 Timer switched off
1 Timer signal is "high“ while the timer is running
2 Timer signal is "low“ while the timer is running
Start condition
Strt
0 Manual start via function key or binary signal (no restart after
mains failure)
1 Automatic start after mains ON (restart after mains failure);
manual start is also possible
Time unit
Unit
0 mm:ss
1 hh:mm
2 hhh.h
Timer value
t1
00.00.
...
999.9.
Timer run time (in the time unit set)
Tolerance band
toLt
0 ...
9999
Tolerance band for timer start
The timer only starts once the actual value has reached the
tolerance band.
0 = Start without tolerance band
Parameters Value Description
