JUMO Quantrol LC300 User Manual

2 Installation - Electrical Connection
12
DANGER!
The electrical installation may carry voltage.
Risk of electrocution.
The electrical connection must only be performed by qualified personnel.
TIP!
Prior to starting the electrical connection, check that the device version complies
with the order code.
Connections Symbol LC100 LC200/LC300
Analog input
Thermocouple 9 10
811
RTD temperature probe, 2-wire 10 9
811
RTD temperature probe, 3-wire 10 9
910
811
Voltage
DC 0 to 10 V
12 7
11 8
Current
DC 0(4) to 20 mA
910
811
Binary input
for potential-free contact
11 7
12 8
Output:12312345
Analog output
DC 0 to 10 V, DC 0(4) to 20 mA
13 12
14 13
Relay output (N/O)
(max. 3 A at AC 230 V, resistive
load)
4136 412141618
5147 513151719
Logic output (DC 0/14 V) 13 7 12 14 16 18
14 6 13151719
RS485 interface 714
615
Output 1 as standard; Outputs 2 to 5 optional (options 1 to 4)
Voltage supply L1 (L+) L1 (L+)
N (L-) N (L-)
Setup interface USB socket, type Mini-B 5-pole
+
-
U
+
-
x
I
x
+
-
x
I
x
U
,
-
+
U
+
-
x
RxD/TxD
+
-
AC/DC
