JUMO Quantrol LC300 User Manual

17
3 Operation - Configuration - Parameterization
3.2.3 Ramp function/firing curve (rAFC)
The device can be operated as a fixed value controller with and without ramp function. In addi-
tion, a firing curve is supported.
ConF -> rAFC ->
3.2.4 Limit value monitoring (Li1, Li2)
The device is equipped with two functions for limit value monitoring (Li 1, Li 2) each with eight
different alarm functions (AF1 to AF8). The two output signals are available for binary functions.
ConF -> LiI , Li2 ->
Parameters Value Description
Function
FnCt
0 Ramp function/firing curve switched off
1 Ramp function Kelvin/Minute
2 Ramp function Kelvin/Hour
3 Ramp function Kelvin/Day
4 Firing curve Kelvin/Minute
5 Firing curve Kelvin/Hour
6 Firing curve Kelvin/Day
Ramp rate
rASL
0 ...
999
Value of the ramp rate (only for function = 1 to 6)
(Setup program: For the firing curve, timer value, time unit and setpoint can also be set here.)
Parameters Value Description
Alarm function
FnCt
0 Limit value monitoring switched off
1 AF1: Limit value above and below the setpoint (monitoring
range); symmetric or asymmetric
2 AF2: As AF1, output signal inverted
3 AF3: Limit value below the setpoint
4 AF4: As AF3, output signal inverted
5 AF5: Limit value above the setpoint
6 AF6: As AF5, output signal inverted
7 AF7: Fixed limit value (setpoint independent)
8 AF8: As AF7, output signal inverted
Limit value
AL, AL2
-1999 ...
0 ...
+9999
Limit value to be monitored
For asymmetrical limit value: AL is below the setpoint, AL2 is
above the setpoint.
Limit value range for AF1 and AF2: 0 to 9999
Switching
differential
HySt
0 ... 1 ...
9999
Switching differential in respect to the limit value
