JUNCTEK JDS8000 Series User Manual

JUNCTEK
JDS8000 Series User’s Manual
5
Depth
0% to 200%
Modulation frequency
1mHz to 1MHz
FM
Carrier waveform
Sine, square, ramp, arbitrary (except DC)
Source
Internal/External
Modulation waveform
Sine waveform, square waveform, ramp waveform,
noise waveform, arbitrary waveform
Modulation frequency
1mHz to 1MHz
Frequency deviation
0.1Hz to 10kHz
PM
Carrier waveform
Sine, square, ramp, arbitrary (except DC)
Source
Internal/External
Modulation waveform
Sine, square, ramp, arbitrary (except DC)
Phase deviation
0° to 360°
Modulation frequency
1mHz to 1MHz
ASK
Carrier waveform
Sine, square, ramp, arbitrary (except DC)
Source
Internal/External
Polarity
Positive and negative
Rate
1mHz to 1MHz
ASK amplitude
0% to 200%
FSK
Carrier waveform
Sine, square, ramp, arbitrary (except DC)
Source
Internal/External
Modulation waveform
Pluse waveform with 50% duty cycle
Polarity
Positive and negative
Rate
1mHz to 1MHz
Frequency hopping
0.1Hz to 80MHz
PSK
Carrier waveform
Sine, square, ramp, arbitrary (except DC)
Source
Internal/External
Polarity
Positive and negative
Rate
1mHz to 1MHz
PSK phase
0° to 360°
PWM
Carrier waveform
Pulse
Wave inversion
Regular and reverse
Pulse period
0.02uS to 40S
Pulse Width
0.020uS to 4S
Burst
Idle
Zero position, positive maximum, negative maximum
Mode
Single, automatic
Trigger source
Manual, CH2 burst, external (AC), external (DC)
