JDS8000 Series User’s Manual
6
Pulse number
1-1048575
External modulation input characteristics
Input signal amplitude range
0~3Vpp
Input signal frequency range
20Hz~20kHz
Sweep characteristics
Sweep channel
CH1 or CH2
Carrier waveform
Sine, square, ramp, arbitrary (except DC)
Sweep function
Sweep frequency, sweep amplitude, sweep duty
Sweep mode
Linear, logarithmic
Sweep direction
Increment, decrement, round trip
Start/stop frequency
Consistent with the upper and lower limits of the
corresponding carrier frequency
Start/stop amplitude
Consistent with the upper and lower limits of the
corresponding carrier amplitude
Start/stop duty cycle
Consistent with the upper and lower limits of the
corresponding carrier duty cycle
Sweep time
0.01S-640S
Voltage control characteristics
Voltage control channel
CH1 or CH2
Carrier wave
Sine wave, square wave, ramp wave, arbitrary wave
(except DC)
Voltage control function
Frequency control, amplitude control, and duty cycle
control
Sweep mode
Linear, logarithmic
Start/stop frequency
Consistent with the upper and lower limits of the
corresponding carrier frequency
Start/stop amplitude
Consistent with the upper and lower limits of the
corresponding carrier amplitude
Start/stop duty cycle
Consistent with the upper and lower limits of the
corresponding carrier duty cycle
Voltage control voltage range
0V-5V, start point and stop point can be set arbitrarily
General parameters
Display
Screen
2.8 inch TFT color LCD screen
Store and load
Quantity
100 groups
Location
00 to 99 (The data of 00 storage location is loaded by
default)
Interface
Interface method
USB to serial interface
Extension interface
Serial port with TTL level, convenient for secondary
development
Communication rate
Standard 115200bps
