Jung Smart Visu Server Series User Manual

SV- SERVER / SV-SERVER-INT 111 / 187
Scene
Activate scene
Scene group
address
8 Bit
18.001
---
---
Activate & learn
scene
Scene group
address
8 Bit
18.001
---
---
Value
/ state
Display 1 bit
(boolean)
----
---
Status
1 Bit
e.g.
1.001
Display 1 byte
(0...100%)
----
---
Value
8 Bit
e.g.
5.010
Display 2 byte
(float)
----
---
Value
16 Bit
e.g.
9.001
Display 4 byte value
(float)
----
---
Value
32 Bit
e.g.
14.056
Display 4 byte value
(signed integer)
----
---
Value
32 Bit
e.g.
13.013
Display 14 Byte
ASCII
----
---
Value
112
Bit
e.g.
16.001
Is a feedback adress blank or switching and feedback address are identical, the following
warning appears:
Abbildung 85: Warning by incomplete function or identical group addresses
