5. OPERATION
Interface assignment
INPUT selection of input source
ANALOG, XLR-1, XLR-2, BNC-1, BNC-2, 2-Wire
INSERT selection of insert connectors (send&return)
off, ANALOG, XLR-2, BNC-2
OUTPUT selection of output mode
normal, 2-Wire
if analog input is selected next menu is
SYNC MODE selection of sync for A/D-converter (also system clock rate)
internal 44.1, 48, 88.2, 96,
INPUT XLR1 (AES/EBU), INPUT EXT (WCLK)
Link
LINK stereo / 2-channel mode
Output format (for XLR1 and BNC1 only)
SRC setting of output sample rate
off, 44.1, 48, 88.2, 96, ext
(Internal reference is available only if ADC is clocked to
external
sync!)
Note: If SRC is switched on, channel status bits will be set to
professional status automatically! If SRC is switched off
channel status bits will not reset. If transparent
(recommended) or consumer status is required, it is to set
individual.
DITHER setting of output word length
off, 20bit, 16bit
STATUS setting of channel status bits
trans (transparent), prof (professional), cons (consumer)
Display adjustment
PEAKHLD peakhold function
on, off
CONTR display contrast
Fader setup
FADE fader on/off, if fader is on current fader position is on display
on, off, fader position display: 00...mute
RNG range of attenuation in dBFS
-10, -20, -40, max (digital zero)
CAL fader calibration
MAX calibration of maximum fader position (push SELECT knob the
if fader is at maximum position) > ok
MIN calibration of minimum fader position(push SELECT knob the
if fader is at minimum position) > ok
Tally assignment
ACCENT has four tally outputs. Following events can be assigned to these outputs (output is
logical high if event is present):
preset 1, preset 2, preset 3, preset 4
bypass on, sync ok, limiter active,
clip (overload, static display, 4 words full scale FFFF),
fader on (fader start)
Operation manual accent2, chapter 5 -Operation- page 5-5
