Jungheinrich ECP 100-3 User Manual

0803.GB
E 4
Item Operating control or indica-
tor
Function
14 Key-operated control
“Operator walking / drive
direction”
o Optional equipment for the “Operator wal-
king” mode:
The truck starts moving in direction (V) with
the operator walking alongside (cut-back
speed).
15 Key-operated control
“Operator walking / fork
direction”
o Optional equipment for the “Operator wal-
king” mode:
The truck starts moving in direction (R) with
the operator walking alongside (cut-back
speed).
16 Deadman key t – When released: travelling function
is blocked or truck coasts to a stop.
– When operated: travelling function is
released.
17 Deadman key
(2nd operating console)
o – When released: travelling function
is blocked or truck coasts to a stop.
– When operated: travelling function is
released.
18 Safety barrier o – open: the lifting and driving
functions are locked above a lifting height
of 1200 mm.
– closed: the lifting and driving
functions are released.
19 2nd master switch
(emergency stop)
o Optional equipment for the “Operator wal-
king” mode:
The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
20 Key-operated control “Ope-
rator walking / fork direction”
o The fork is lifted (auxiliary lift).
21 Key-operated control “Ope-
rator walking / drive direc-
tion”
o The fork is lowered (auxiliary lift).
22 Key “Lowering” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lowered.
23 Key “Lifting” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lifted.
t = Standard equipment o = Optional equipment
0803.GB
E 4
Item Operating control or indica-
tor
Function
14 Key-operated control
“Operator walking / drive
direction”
o Optional equipment for the “Operator wal-
king” mode:
The truck starts moving in direction (V) with
the operator walking alongside (cut-back
speed).
15 Key-operated control
“Operator walking / fork
direction”
o Optional equipment for the “Operator wal-
king” mode:
The truck starts moving in direction (R) with
the operator walking alongside (cut-back
speed).
16 Deadman key t – When released: travelling function
is blocked or truck coasts to a stop.
– When operated: travelling function is
released.
17 Deadman key
(2nd operating console)
o – When released: travelling function
is blocked or truck coasts to a stop.
– When operated: travelling function is
released.
18 Safety barrier o – open: the lifting and driving
functions are locked above a lifting height
of 1200 mm.
– closed: the lifting and driving
functions are released.
19 2nd master switch
(emergency stop)
o Optional equipment for the “Operator wal-
king” mode:
The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
20 Key-operated control “Ope-
rator walking / fork direction”
o The fork is lifted (auxiliary lift).
21 Key-operated control “Ope-
rator walking / drive direc-
tion”
o The fork is lowered (auxiliary lift).
22 Key “Lowering” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lowered.
23 Key “Lifting” o Optional equipment “Pedestrian-controlled
operation”:
The fork is lifted.
t = Standard equipment o = Optional equipment
