Jungheinrich ECP 100-3 - Opening the Door to the Electrical System

F 9
0803.GB
A
The drive unit and the hydraulic system can be accessed for servicing purposes.
Installation occurs in the reverse order of steps.
f
Do not drive the truck unless the hoods are closed and locked in the stipulated man-
ner.
6.4 Opening the door to the electrical system
– Open the battery hood (refer to chapter D).
– Pull out the door locking mechanism (4) and open the door to the electrical system
(5).
A
The drive current control system and the truck fuses can be accessed for servicing
purposes.
4
5
