Jungheinrich ECP 100-3 User Manual

0803.GB
E 6
Item Operating control or indica-
tor
Function
24 Steering wheel
(2nd operating console)
o Steers the truck.
25 Pushbutton
“Two-hand operation”
(2nd operating console)
o Releases the lifting and driving functions
when pressed (in the rail guidance mode
with aisle recognition).
26 Controller (2nd operating
console)
o Controls the direction of travel as well as
the travelling speed.
27 Key “Warning signal”
(horn)
o Gives an audible warning signal.
28 2nd master switch
(emergency stop)
(2nd operating console)
o Optional equipment for the “Operator wal-
king” mode:
The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
29 Key “Lifting”
(2nd operating console)
o The fork is lifted.
30 Key “Lowering”
(2nd operating console)
o The fork is lowered.
31 Pushbutton “Two-hand ope-
ration” FME fork “Lifting”
o Lifting the FEM fork (auxiliary lift).
(in addition to pushbutton 30)
32 Pushbutton “Two-hand ope-
ration” FME fork “Lowering”
o Lowering the FEM fork (auxiliary lift).
(in addition to pushbutton 33)
33 Key “Lifting” o The fork is lifted.
34 Key “Lowering” o The fork is lowered.
t = Standard equipment o = Optional equipment
0803.GB
E 6
Item Operating control or indica-
tor
Function
24 Steering wheel
(2nd operating console)
o Steers the truck.
25 Pushbutton
“Two-hand operation”
(2nd operating console)
o Releases the lifting and driving functions
when pressed (in the rail guidance mode
with aisle recognition).
26 Controller (2nd operating
console)
o Controls the direction of travel as well as
the travelling speed.
27 Key “Warning signal”
(horn)
o Gives an audible warning signal.
28 2nd master switch
(emergency stop)
(2nd operating console)
o Optional equipment for the “Operator wal-
king” mode:
The circuit is interrupted, all electrical
functions are switched off and the truck is
automatically braked.
29 Key “Lifting”
(2nd operating console)
o The fork is lifted.
30 Key “Lowering”
(2nd operating console)
o The fork is lowered.
31 Pushbutton “Two-hand ope-
ration” FME fork “Lifting”
o Lifting the FEM fork (auxiliary lift).
(in addition to pushbutton 30)
32 Pushbutton “Two-hand ope-
ration” FME fork “Lowering”
o Lowering the FEM fork (auxiliary lift).
(in addition to pushbutton 33)
33 Key “Lifting” o The fork is lifted.
34 Key “Lowering” o The fork is lowered.
t = Standard equipment o = Optional equipment
