4 Position of signs and nameplates
NOTICE The vehicle nameplate (23) can be accessed by opening the front cover (see
Chapter F).
Item Designation
15 Sign - Qmax
16 Danger battery 2x (1x opposite)
17 Warning battery size 2x (1x opposite)
18 Warning stay clear
19 Attachment point for handling by crane
20a Warning jog button coast, left (o)
20b Warning jog button coast, right (o)
21 Nameplate, battery
22 Attachment point for jack
23 Nameplate, vehicle
24 Warning stay clear stop truck
25 Warning charger
26 Vehicle serial number
27 Warning electrical device
28 Warning coast system (o)
16
20a
20b
25
19
22
23
23
26
28
27
19
22
17
21
24
15
18
opposite
(not shown)
