Jungheinrich ECR 327 - Uncovering and Charging the Battery

F 3
0705.USA
3 Uncovering the battery
QwW Switch off and secure the vehicle (see Chapter E).
– Turn the switch latch (1) to the "OFF" position.
– Lift the safety guard latch (4) and carefully fold down the safety guard (3, o).
QwK Hold onto the safety guard (3) as you fold it down.
– Lift up the battery cover (2).
4
3
2
1
