0705.USA
E Operation
1 Description of controls and indicators
Item Control or indicator
Function
1 Switch latch t Switches the control current on and off. Remove
the key to prevent the vehicle being switched on by
unauthorized persons.
2 Discharge indicator (EA) t Displays the battery capacity
3 Information display (CANDIS) o Operating hours indicator
Shows the residual battery capacity and the
number of operating hours already completed by
the vehicle
4 Keypad (CANCODE) o Code settings, access authorization
Travel program enabling
5 Access module ISM o Starts/switches off the vehicle.
Displays important information, prompts, shock
events, and error messages.
Sets date and time.
6 Tiller t Swiveling tiller; steering and braking
7 Jog button o Travel switch for travel in tiller direction. Coasting
at 5.6 km/h (3.5 mph).
8 Travel regulator t Controls the direction of travel and speed (see
Section 4.2).
9 "Down" rocker switch t Lowers the fork.
10 "Up" rocker switch t Raises the fork.
11 Anti-collision button t Safety function. Automatically moves the vehicle
for approximately 3 s in the direction of travel (R)
and then switches it off until the travel regulator is
moved briefly to neutral.
12 Warning signal button (horn) t Sounds the warning signal.
13 Tiller locking lever o Locks the tiller in the travel position.
14 Jog button o Travel switch for travel in tiller direction. Coasting
at 5.6 km/h (3.5 mph).
15 Brake button o Brakes the vehicle mechanically.
16 High-speed button t Moves the vehicle in ride-on mode at 15 km/h,
max. (9.3 mph) in the tiller direction or 9.0 km/h,
max. (5.6 mph) in the fork direction.
t = Fitted as standard o = Optional extra
