Model EJD 220
x Load distance 1) 957 mm
y Wheel base 1) 4) 1617 mm
h3 Lift 5) 1660 mm
h5 Initial lift 122 mm
h13 Lowered height 90 mm
h14 Tiller height in the travel position min./max. 711 / 1320 mm
L1 Length 4) 2022 mm
L2 Fork length including fork shank 4) 832 mm
b1/2 Overall width (drive) 726 mm
b5 Width across forks 570 mm
s/e/l Fork dimensions 56 / 185 / 1190 mm
b10 Track width, front 508 mm
b11 Track width, rear 385 mm
m2 Ground clearance, centre wheelbase 20 mm
Ast Aisle width
with pallet 1000x12000 traverse 2) 4)
2233 mm
Ast Aisle width
with pallet 800x1200 longit. 3) 4)
2243 mm
Wa Turning radius 1) 4) 1800 mm
1) Load section lowered + 48 mm
2) Load section lowered + 48 mm; diagonal in accordance with VDI + 369 mm
3) Load section lowered + 48 mm; diagonal in accordance with VDI + 225 mm
4) Battery compartment M version / battery compartment L version = version M +
72 mm
5) Values for standard mast 166ZT
25
04.19 en-GB
