Flashing sequence / charging curve assignment (ELG 2430)
Flashing sequence Selected charging curves (characteristics)
0 Truck without battery
1
Wet cell battery: PzS with 100 - 300 Ah
Wet cell battery: PzM with 100 - 179 Ah
2 Maintenance-free: PzV with 100 - 149 Ah
3 Maintenance-free: PzV with 150 - 199 Ah
4 Maintenance-free: PzV with 200 - 330 Ah
5
Wet cell battery: PzS with pulse characteristic 200 -
400 Ah
Wet cell battery: PzM with pulse characteristic 180 -
400 Ah
Wet cell battery: PzS with pulse characteristic 200 -
414 Ah
6 Jungheinrich 100 - 300 Ah
NOTICE
u
All other switch positions (48) block the battery charger, and the battery is not
charged.
u
Set characteristic curve 1 for PzM batteries with capacities less than 180 Ah and
characteristic curve 5 above 180 Ah.
u
Both characteristic curves 1 and 5 can be used for PzS 200 - 300 Ah wet-cell
batteries, whereby curve 5 results in faster charging.
u
When the battery is connected, this allows you to adjust via the battery charger: If
the switch position is valid, the green LED flashes according to the position set; if
the switch position is invalid, the red LED flashes.
49
04.19 en-GB
