Samtec Cable Specicaons
Electrical Characteriscs
Impedance 50 Ω
Frequency 3GHz
Dielectric Withstanding Voltage 750 V
V.S.W.R 1.3 max
Antenna Cable Specicaons
IN THIS SECTION
LMR400 (10-m Segment) Cable Specicaons | 8
LMR400 (95-m Segment) Cable Specicaons | 9
LMR400 (5-m Segment) Cable Specicaons | 10
The following topology (Figure 1 on page 8) depicts the antenna cable connecons with connector types. Use this
topology as an example to install the antenna cables.
